Overview
A masterful cutaway isometric drawing of St. Paul's Cathedral, revealing the complex 'triple-shell' construction of Christopher Wren's iconic dome. This specific print is dedicated to William Dunn and was measured and drawn by R.B. Brook-Greaves under the direction of Sir Mervyn Macartney.
Story
In 1923, St. Paul's was declared dangerous due to structural shifting. This drawing was part of a massive effort to document and save the cathedral, revealing secrets of the dome's hidden brick cone for the first time.
Maker / Origin
Sir Mervyn Macartney was the Surveyor of the Fabric of St. Paul's and a founding member of the Art Workers' Guild. He worked with R.B. Brook-Greaves, a brilliant draughtsman who spent years suspended in the cathedral's heights to capture these precise measurements.
Condition & Value
The print appears well-preserved under glass, though there is visible toning to the paper consistent with age. The dark matting is a modern addition; original condition of the paper edges behind the mat is unknown. Good condition overall.
